instrumentation cable seriesDetects Fuel · Ignores WaterGasoline, Jet A-1 & Diesel4-Wire ±1 m Pinpoint

TraceTek TT5000 Hydrocarbon Fuel and Solvent Leak DetectionWater-immune swelling-polymer hydrocarbon fuel, diesel & jet-fuel leak sensing cable

TraceTek TT5000 Hydrocarbon Fuel and Solvent Leak Detection Sensing Cable engineered with a hydrocarbon-absorbent swelling silicone-elastomer actuator layer that physically presses two internal conductive-polymer sensing wires (~20.

Hydrocarbon Selective
100 % Immune to Water
Ex ia / EPA UST Compliant
Sumped & Buried Containment
Order designation
TraceTek TT5000-PC
Cable body Ø
9.5 mm
Weight ≈
88 kg/km
Jet/Petrol response
5 min
#2 Diesel response
30 min
All sizes (3)
Request a quoteDatasheetWhatsApp
Engineering reply in 2 business hoursCut-to-length export drumsEN 10204 3.1 certificate per drum
Selectivity
Fuel only (No H₂
Ignores rain & groundwater
Target fluids
Jet, diesel, pet
Kerosene, crude, biodiesel, BTX
Outer diameter
9.0 to 10.5 mm
With protective outer braid
Sensor resistance
≈ 20.0 Ω/m
Standard 4-wire locating loop
Ex classification
Ex ia IIC T4 Ga
Simple apparatus with barrier
Operating temp.
-20 to +60 °C
Fuel containment trenches/pipes

Typical values for this cable type, based on UL 913 / IEC 60079-11 / EPA 40 CFR 280 — confirmed in the datasheet and quotation for your order.

Application fit

Is TraceTek TT5000 right for your machine?

Purpose-built for wet sumps, underground storage tank (UST) interstitial spaces, airport hydrant fuel trenches and data-centre belly-tank generator rooms where water is always present but only hydrocarbon fuel leaks must trigger an alarm.

Fixed installation

Suitable

Installed in double-containment fuel transfer pipes, generator day-tank pans and airport Jet A-1 hydrant pits.

Immersion & wet locations

Suitable

Can remain submerged in water or damp soil without false alarms, yet triggers when a thin sheen of fuel contacts the jacket.

Offshore platform & shipboard deck trays

Suitable

Passive 4-wire loop qualifies as an Intrinsically Safe 'Simple Apparatus' (Ex ia IIC) when driven through an approved zener barrier.

Energy chain / drag chain

Not suitable

Static hydrocarbon containment sensing cable; not for dynamic machinery drag chains.

Use PUR-HF Drag-Chain Cable
Typical machinesData-Centre Standby Diesel Generator RoomsAirport Jet A-1 Hydrant Pipelines & Valve PitsUnderground Storage Tank (UST) Double-ContainmentRefinery, Tank Farm & Pipeline Trench MonitoringMarine Bunker & Turbine Lube-Oil Skids

Construction

Layer by layer

TraceTek TT5000 showing central support core, 2 fluoropolymer-insulated copper continuity wires, 2 concentric conductive-polymer sensing electrodes separated by a calibrated gap, hydrocarbon-swelling elastomer jacket, and black/yellow chemical-resistant outer braid.

1234
Schematic, not to scale — generated from the layer data
#LayerMaterial & reference
12 × insulated copper reference & continuity wires2 × 26 AWG stranded tinned copper conductors with fuel-proof fluoropolymer insulationMonitors end-to-end cable integrity and completes the 4-wire locating bridge
2Inner conductive-polymer sensing electrode + spacerInner calibrated conductive-polymer electrode (~20.0 Ω/m) separated from the outer sensing wire by an open helical gapWater cannot compress the gap; non-conductive fuels cannot conduct electrically on their own
3Hydrocarbon-absorbent swelling elastomer actuatorProprietary cross-linked organosilicone/elastomer matrix that swells rapidly upon absorbing liquid hydrocarbonsRadial swelling forces the outer conductive sensing wire against the inner sensing electrode
4Protective high-tenacity polymer outer braidAbrasion-resistant Black/Yellow woven fluoropolymer/polyester outer braid (nominal 9.5–10.5 mm OD)Allows smooth pulling into slotted conduits while letting fuel wick through

TraceTek TT5000 (Bulk Reel)

Bulk hydrocarbon fuel sensing cable for pulling into containment conduits and pipeline trenches

TraceTek TT5000-MC / TT5000-PC (Modular)

Pre-terminated modular lengths (1.5 m, 3 m, 7.5 m, 15 m) with metal or plastic connectors for generator pans

Technical data

Ratings & operating limits

Typical values: Typical values for this cable type, based on UL 913 / IEC 60079-11 / EPA 40 CFR 280. Values for your order are confirmed in the datasheet and quotation.

Electrical

Sensing wire linear R
≈ 20.0 Ω/m (±2 % linearity — uses standard TTDM/TTSIM modules)
Dry / water-immersed IR
≥ 100 MΩ in dry air or clean tap/rainwater
Location accuracy
± 0.5 % of total sensing circuit length
Intrinsic safety rating
Ex ia IIC T4 Ga (Simple Apparatus per IEC 60079-11 Cl. 5.7)

Thermal

Continuous operating temp.
-20 °C to +60 °C
Storage temperature
-30 °C to +70 °C
Response time @ 20 °C
≈ 3–8 min (Gasoline / Jet A-1) · ≈ 15–45 min (#2 Diesel)

Mechanical

Nominal outer diameter
9.5 mm (cable body) · 14–19 mm (at modular connector)
Min. bend radius
50 mm (5 × OD)
Max. pulling tension
220 N (50 lbf)

Resistance

Detected hydrocarbons
Gasoline, Jet A / JP-8, #1/#2 Diesel, Kerosene, Toluene, Xylene
Water & methane immunity
Does not alarm in liquid water or gaseous methane/natural gas
Volatile fuel recovery
Can reset after light gasoline/solvent evaporation (replace after heavy diesel saturation)

Reference standards

UST leak detection
US EPA 40 CFR Part 280 & NWGLDE Third-Party Listed
Hazardous locations
UL 913 / FM Class I Div 1 & ATEX/IECEx Zone 0 (with barrier)
RoHS & REACH
2011/65/EU & EC 1907/2006 compliant

Identification

Visual identification
Black outer braid with Yellow tracer & fuel warning tag
Customs tariff (HS)
8544.4290
System compatibility
Mix-and-match on same 4-wire loop with TT1000 / TT3000 / TT5001

Sizes

3 standard TraceTek TT5000 hydrocarbon sensing configurations

Dimensions, linear sensing resistance and typical response times for gasoline, jet fuel and diesel.

Dimensions & hydrocarbon response
Order designationSupply format & dutyBody Ø
mm		Weight ≈
kg/km		Jet/Petrol
min		#2 Diesel
min		Enquiry
4-Wire Swelling-Polymer Hydrocarbon Fuel Sensing Cables
TraceTek TT5000 (Bulk)Bulk Reel for Slotted Conduit & Pipe Pull-In9.588530
TraceTek TT5000-PCModular Plastic Connectors (1.5 m to 15 m) · Wet Sumps9.588530
TraceTek TT5000-MCModular Metal Connectors · Indoor Generator Rooms9.588530
  • Typical values for this cable type; dimensions and weights for your order are confirmed in the quotation.
  • For ultra-fast response (< 1–3 min) to light organic solvents (MEK, acetone, benzene, toluene), see TraceTek TT5001 / TT5001-HUV.

Quality & approvals

Testing & inspection

Routine tests on every production length, sample and type tests per batch — documented on an EN 10204 3.1 inspection certificate.

  1. ConductorClass 5 stranding
  2. Spark test100 % in-line
  3. Lay-upCores, earth, fillers
  4. SheathingInner, braid / screen, outer
  5. Electrical testsAC voltage, resistance
  6. DimensionsOD, wall thickness
  7. Inspection documents & dispatchDrum & dispatch
Testing & inspectionTest value / referenceFrequency
Routine tests
100 % linear sensing resistance (20.0 Ω/m) & dry IR test20.0 Ω/m ± 2 % and open-circuit IR ≥ 100 MΩEvery manufactured reel / assembly
Sample tests
Iso-octane / Jet A-1 / #2 Diesel response time verificationMeets batch swelling actuation time limitsPer production lot
EPA / NWGLDE water-immersion + floating hydrocarbon sheen testZero false alarm in water; positive alarm & location on 3 mm fuel layerQualification test

Inspection certificate

Issued with every drum, listing the routine test results for that length.

Product approvals

EPA 40 CFR 280 / NWGLDEEx ia IIC Simple ApparatusCE, RoHS 2 & REACH

Company certificates

ISO 9001ISO 14001ISO 45001VDE marks approvalUL / cULCE · LVD / EMC

Marking & supply

Ordering & delivery

Sheath marking

Tag & connector print: TEBAOFLEX TRACETEK TT5000 FUEL/SOLVENT
Delivery form
Fumigated wooden drums, steel reels or precision spools
Standard lengths
500 m · 1000 m (or custom cut/spooled lengths)
MOQ
100 m (standard) · 500 m (custom)
Lead time
2–4 weeks ex-works
Incoterms
EXW, FOB, CIF, DAP

Technical documents

Downloads

PDFTraceTek TT5000 Hydrocarbon Fuel and Solvent Leak Detection – technical datasheet3 sizes · construction, technical data, approvalsXLSXTraceTek TT5000 spec data (Excel)All 3 sizes with dimensions and data, for your BOM or quotation
Revision
2026-10-20
Updated
2026-10-20

FAQ

Questions engineers ask first

Not covered here? Send your drawing — an engineer replies within 2 business hours.

How can TT5000 detect electrically non-conductive hydrocarbons like diesel and jet fuel while completely ignoring conductive water?
Unlike water-sensing cables (TT1000/TT3000) which rely on the liquid itself to conduct electricity between two exposed wires, TT5000 keeps its two conductive-polymer sensing wires sealed inside a water-impermeable jacket separated by an internal gap. Surrounding the core is a specially formulated silicone-elastomer layer that does not absorb water, but swells forcefully when exposed to liquid hydrocarbons—mechanically pinching the two internal 20 Ω/m sensing wires together to trigger the alarm and distance calculation.
Can TT5000 and TT1000 be connected to the same alarm panel in a data-centre generator room?
Yes. Because both TT5000 and TT1000 use the exact same 4-wire ~20.0 Ω/m voltage-divider architecture, they use the same TTSIM / TTDM-128 monitoring modules and can even be daisy-chained in separate zones.
When should we choose TT5001 / TT5001-HUV instead of TT5000?
Choose TT5000 for refined fuels (diesel, gasoline, Jet A-1, kerosene, hydraulic/lube oil). Choose TT5001 (indoor) or TT5001-HUV (outdoor UV-stabilized) when you need sub-minute fast response to volatile organic solvents (MEK, acetone, toluene, xylene, benzene) in pharmaceutical or chemical plants.
Is TT5000 safe to install inside Class I Division 1 / ATEX Zone 0 fuel sumps?
Yes. The sensing cable contains no energy-storing components (inductance/capacitance are negligible) and qualifies as an Intrinsically Safe 'Simple Apparatus' per IEC 60079-11 / UL 913 when connected through an approved intrinsic-safety zener barrier.
