Control & signal cablesJIS C 3410 MarineIndividual Pair Screen (-S)MPY-S / MPYC-S / MPYCY-S

MPY-S / MPYC-S / MPYCY-S JIS Individually Screened ShipboardJIS C 3410 250 V individually pair-screened EP-rubber marine instrumentation cable

Individually pair/core-screened 250 V marine shipboard instrumentation cable family to JIS C 3410 (`MPY-S`, `MPYC-S`, `MPYCY-S`). Each +90 °C EP-rubber pair is wrapped in its own copper/Al-foil screen (`-S`) to eliminate inter-channel crosstalk.

Flame-retardant
Oil-resistant
Water-resistant
Approved
Order designation
MPYCY-S 4×2×1.25
Outer Ø min
17.8 mm
Outer Ø max
19.4 mm
Weight ≈
565 kg/km
Min. bend R
116 mm
Check against my drumAll sizes (16)
Request a quoteDatasheetWhatsApp
Engineering reply in 2 business hoursCut-to-length export drumsEN 10204 3.1 certificate per drum
Voltage rating
250 V
150/250 V AC · JIS C 3410 pair-screened
Pair screen
Individual '-S'
Each pair separately foil/Cu screened
Conductor temp.
+90 °C max.
+90 °C continuous · EP rubber cores
Flame test
IEC 60332-3-22
Category A bunched vertical flame test
Bending radius
6 × OD
6 × overall diameter fixed installation
Size range
0.75–1.5 mm²
1×2 to 24×2 pairs · 3 armour variants

Typical values for this cable type, based on JIS C 3410 / IEC 60092-376 — confirmed in the datasheet and quotation for your order.

Application fit

Is MPY-S / MPYC-S / MPYCY-S right for your machine?

The hyphenated `-S` series (`MPY-S`, `MPYC-S`, `MPYCY-S`) encloses each individual pair (or triad) in its own metallic screen and numbered identification tape, preventing mutual crosstalk between mixed 4–20 mA, thermocouple, RTD and pulse tachometer signals on board ships.

Fixed installation

Suitable

Multi-pair marine instrumentation, main engine exhaust/bearing sensors, cargo radar gauging and ECR marshalling.

VFD inverter to AC motor screened feeder

Suitable

Individual pair screens plus outer wire-braid armour (MPYC-S / MPYCY-S) suppress both inter-pair crosstalk and VFD noise.

Trailing & towing

Not suitable

Fixed shipboard installation cable; not designed for dynamic trailing duty.

Use LiYCY (TP)

Energy chain / drag chain

Not suitable

When only a single collective screen is needed over all cores, select MPYS / MPYCS / MPYCYS.

Use MPYS / MPYCYS
Typical machinesMain engine RTD, thermocouple & pressure loopsCargo tank radar & custody-transfer gaugingIntegrated bridge & propulsion control systemsLNG carrier & chemical tanker safety interlocksOffshore drilling & production instrumentation

Construction

Layer by layer

Shown: MPYCY-S 4×2×1.25 mm² — 7-wire stranded copper conductors, +90 °C EP-rubber pair insulation ('P'), individual copper/Al-Mylar screen + drain wire on each pair ('-S'), PVC inner bedding ('Y'), wire-braid armour ('C') and black PVC outer oversheath ('Y').

12345
Schematic, not to scale — generated from the layer data
#LayerMaterial & reference
1Stranded annealed copper conductor7-wire circular stranded annealed copper to JIS C 3102 / IEC 60228 Class 2JIS C 3410 / IEC 60228 Cl. 2
2EP-rubber pair insulation (P)+90 °C cross-linked ethylene-propylene rubber (EPR) twisted into pairs with pair identificationJIS C 3410 · IEC 60092-360 EPR
3Individual pair screen (-S)Copper tape/braid or aluminium-polyester tape + tinned drain wire + numbered isolation tape over each individual pairJIS C 3410
4Vinyl sheath (Y)Flame-retardant PVC outer sheath (on MPY-S) or inner bedding sheath (on MPYC-S / MPYCY-S)JIS C 3410
5Optional wire braid + oversheath (C / CY)Unarmoured (MPY-S), galvanised steel/Cu wire braid (MPYC-S), or wire braid + PVC outer oversheath (MPYCY-S)JIS C 3410 · IEC 60332-3-22 Cat. A

MPY-S (Individually Screened Pairs + PVC Sheath)

Unarmoured multi-pair shipboard instrumentation cable for bridge consoles and dry ECR cabinets

MPYC-S (Individually Screened Pairs + Wire Braid Armour)

Adds exposed galvanised steel or copper wire braid armour over the pair-screened core assembly

MPYCY-S (Individually Screened Pairs + Braid + PVC Oversheath)

Full engine-room and deck specification with individual pair screens, wire braid armour and outer PVC oversheath

Technical data

Ratings & operating limits

Typical values: Typical values for this cable type, based on JIS C 3410 / IEC 60092-376. Values for your order are confirmed in the datasheet and quotation.

Electrical

Rated voltage
250 V (150/250 V AC)
AC test voltage (50/60 Hz)
1500 V AC for 5 minutes (core/core & core/pair-screen)
Max. DC conductor resistance (20 °C)
0.75 mm²: ≤ 25.3 Ω/km · 1.25 mm²: ≤ 15.0 Ω/km · 1.5 mm²: ≤ 12.1 Ω/km
Inter-pair crosstalk attenuation
≥ 75 dB via individual metallic pair screens
Insulation resistance (20 °C)
≥ 1000 MΩ·km (EP rubber)

Thermal

Max. conductor temperature
+90 °C continuous operation
Short-circuit temperature
+250 °C max. (5 s)
Fixed ambient range
−25 °C to +80 °C

Mechanical

Min. bending radius, fixed
6 × overall diameter
Pair screen isolation
Each screened pair is wrapped in numbered insulating tape so individual screens remain isolated or selectively grounded

Resistance

Bunched flame test
IEC 60332-3-22 Category A & IEC 60332-1-2 vertical flame retardant
Marine oil & moisture
Outer PVC oversheath (MPYCY-S) resists bilge water, fuel oil and salt mist

Reference standards

Primary standard
JIS C 3410
IEC alignment
IEC 60092-350, IEC 60092-360 & IEC 60092-376
Marine society scope
Designed to NK, ABS, DNV, LR, BV and CCS classification rules
RoHS & SOLAS
RoHS 2 & SOLAS asbestos-free compliant

Identification

Sheath colour
Black or grey marine PVC
Pair identification
Colour-coded pair cores (e.g. white/black) with sequential pair number printed on the screen tape
Sheath marking
TEBAOFLEX JIS C 3410 MPYCY-S 250V [n×2×mm²] PAIR SCREENED CAT.A
Customs tariff (HS)
8544.49 (insulated conductors ≤ 1000 V)

Sizes

16 standard MPY-S / MPYC-S / MPYCY-S configurations

Typical JIS C 3410 / IEC 60092-376 outer diameter limits, copper content and cable weight.

Dimensions & weights
Order designationCores × mm²AWG ≈Outer Ø min
mm		Outer Ø max
mm		Copper
kg/km		Weight ≈
kg/km		Min. bend R
mm		Enquiry
n × 2 × 0.75 mm² Individually Screened Pairs (MPY-S / MPYC-S / MPYCY-S)
MPYCY-S 1×2×0.751×2×0.751810.911.82219571
MPYCY-S 2×2×0.752×2×0.751814.015.24232091
MPYCY-S 4×2×0.754×2×0.751816.417.882465107
MPYCY-S 7×2×0.757×2×0.751819.120.8140665125
MPYCY-S 12×2×0.7512×2×0.751824.126.22381,020157
MPYCY-S 19×2×0.7519×2×0.751828.330.83751,450185
n × 2 × 1.25 mm² Individually Screened Pairs (MPY-S / MPYC-S / MPYCY-S)
MPYCY-S 1×2×1.251×2×1.251611.612.63222876
MPYCY-S 2×2×1.252×2×1.251615.116.46237898
MPYCY-S 4×2×1.254×2×1.251617.819.4122565116
MPYCY-S 7×2×1.257×2×1.251621.022.8212825137
MPYCY-S 12×2×1.2512×2×1.251626.729.03601,290174
n × 2 × 1.50 mm² Individually Screened Pairs (MPY-S / MPYC-S / MPYCY-S)
MPYCY-S 1×2×1.51×2×1.51612.013.03724478
MPYCY-S 2×2×1.52×2×1.51615.617.072408102
MPYCY-S 4×2×1.54×2×1.51618.620.2142618121
MPYCY-S 7×2×1.57×2×1.51621.923.8248912143
MPYCY-S 12×2×1.512×2×1.51627.830.24221,435181
  • Typical values for this cable type; dimensions and weights for your order are confirmed in the quotation.
  • Dimensions and weights are typical values per JIS C 3410 / IEC 60092-376. Minimum fixed bending radius shown is 6 × OD.

Reel check

Will it fit your machine?

A first screen using datasheet values. Engineering confirms drum geometry, acceleration and tension with your quotation.

Check results

Drum core 300 mm ≥ 232 mmBending radius OK (6 × OD 19.4 mm)
Minimum bending radius
116 mm
Min. drum core diameter
≈ 232 mm
Cable weight on drum
28.3 kg
Copper content
6.1 kg
Indicative only: based on the datasheet outer diameter and 6 × OD bending radius. Current derating for wound layers per DIN VDE 0298-4 is assessed separately.

Quality & approvals

Testing & inspection

Routine tests on every production length, sample and type tests per batch — documented on an EN 10204 3.1 inspection certificate.

  1. ConductorClass 5 stranding
  2. Spark test100 % in-line
  3. Lay-upCores, earth, fillers
  4. SheathingInner, braid / screen, outer
  5. Electrical testsAC voltage, resistance
  6. DimensionsOD, wall thickness
  7. Inspection documents & dispatchDrum & dispatch
Testing & inspectionTest value / referenceFrequency
Routine tests
AC voltage test1.5 kV AC (50 Hz)Every manufactured length
Conductor DC resistanceIEC 60228 / JIS C 3410 / IEC 60092-376 (bare copper)Every manufactured length
Sample tests
Vertical flame propagationIEC 60332-1-2 / EN 60332-1-2Per production batch
Insulation & sheath material physical propertiesJIS C 3410 / IEC 60092-376Type approval

Inspection certificate

Issued with every drum, listing the routine test results for that length.

Product approvals

JIS C 3410 / IEC 60092-376CE · RoHS 2 (2011/65/EU) · REACH

Company certificates

ISO 9001ISO 14001ISO 45001VDE marks approvalUL / cULCE · LVD / EMC

Marking & supply

Ordering & delivery

Sheath marking

TEBAOFLEX JIS C 3410 MPYCY-S 250V [n×2×mm²] IEC 60332-3-22 CAT.A
Delivery form
Export wooden drums or coils, cut-to-length on request
Packaging
Heat-treated ISPM-15 timber drums with sealed cable ends
Conductor / sheath options
Custom core counts, pair counts or sheath colours on request

Technical documents

Downloads

PDFMPY-S / MPYC-S / MPYCY-S JIS Individually Screened Shipboard – technical datasheet16 sizes · construction, technical data, approvalsXLSXMPY-S / MPYC-S / MPYCY-S spec data (Excel)All 16 sizes with dimensions and data, for your BOM or quotation
Revision
2026-10-20
Updated
2026-10-20

FAQ

Questions engineers ask first

Not covered here? Send your drawing — an engineer replies within 2 business hours.

What does the hyphenated '-S' mean in MPY-S, MPYC-S and MPYCY-S?
In JIS C 3410 nomenclature, '-S' with a hyphen indicates that each twisted pair (or individual core) is enclosed in its own metallic electrostatic screen and insulating number tape before the pairs are cabled together. By contrast, 'S' without a hyphen (MPYS, MPYCS, MPYCYS) denotes a single collective screen around the whole bundle.
When do shipboard engineers specify MPYCY-S over MPYCYS?
Specify MPYCY-S when a single multi-pair home-run cable carries heterogeneous signals — for example, mixing millivolt thermocouple/RTD loops, 4–20 mA transmitters and 24 V digital pulse tachometers — where capacitive crosstalk between pairs inside the cable must be completely blocked.
How are the individual pairs identified during termination?
Each pair uses colour-coded +90 °C EP-rubber cores (typically white and black) wrapped in its metallic screen and an outer polyester/textile tape printed with the pair number (1, 2, 3…).
Which mechanical outer protection should I select: MPY-S, MPYC-S or MPYCY-S?
Select MPY-S (PVC outer sheath, unarmoured) for internal bridge and control-room consoles; MPYC-S (exposed wire-braid armour) for dry machinery spaces; and MPYCY-S (wire-braid armour + outer PVC oversheath) for engine rooms, pump rooms and weather decks.
