Heavy-duty rubber cables (NSSHÖU)PN-91/E-90103 · Mining450/750 V & 0.6/1 kVEPR · ON-3 / EM2 PCP

OnG CablePolish PN-E-90103 450/750 V & 0.6/1 kV flame-retardant oil-resistant mining rubber cable

Heavy-duty Polish mining and industrial rubber cable ('O' = oponowy rubber tire cable, 'n' = flame/oil-resistant, 'G' = górniczy mining) to PN-91/E-90103 / PN-89/E-90143 in 450/750 V and 0.6/1 kV with Class 5 copper, +90 °C EPR cores and PCP sheath.

Oil-resistant

Flame-retardant

Ozone, UV & moisture

Outdoor & humid

Cores × cross-section

Order designation: OnG 4×25
Outer Ø min: 27.8 mm
Outer Ø max: 30.2 mm
Weight ≈: 1,780 kg/km
Min. bend R: 121 mm

Check against my drum All sizes (24)

Request a quote Datasheet WhatsApp

Engineering reply in 2 business hoursCut-to-length export drumsEN 10204 3.1 certificate per drum

Rated voltage: 0.6/1 kV
Conductor temp.: +90 °C max.
Ambient temp.: −25…+70 °C
Bending radius: 4–6 × OD
Compounds: GIE1 / ON-3
Size range: 1.5–240 mm²

Typical values for this cable type, based on PN-91/E-90103 / PN-89/E-90143 — confirmed in the datasheet and quotation for your order.

Application fit

Is OnG right for your machine?

OnG is the standard Polish heavy-duty rubber trailing cable approved for underground mining excavations outside methane-explosion Grade 'b'/'c' zones as well as open-pit mines, quarries, coal preparation plants and heavy construction machinery.

Trailing & towing

Suitable

Mobile mining machinery, open-pit excavators, quarry crushers, drilling rigs and heavy workshop feeders.

Festoon & line chain

Suitable

Overhead crane festoons, coal handling conveyors and heavy industrial hoists.

Fixed installation

Suitable

Underground mine excavations, preparation plants, tunnels and outdoor industrial installations.

Motorised monospiral reel

With conditions

Suitable for slow coiling; for high-speed motorised crane reeling under tension, select NSHTÖU.

Use NSHTÖU Reeling

Typical machinesUnderground & open-pit coal/copper minesMineral processing & coal wash plantsQuarries, cement & aggregate worksHeavy construction & tunnelling gearSteelworks, coking plants & foundries

Construction

Layer by layer

Shown: OnG 4×25 0.6/1 kV — Class 5 copper conductors, separator foil, +90 °C EPR core insulation (GIE1), elastomeric inner filling and heavy-duty black flame-retardant oil-resistant polychloroprene outer sheath (ON-3 / EM2).

Schematic, not to scale — generated from the layer data

#	Layer	Material & reference
1	Flexible copper conductor	Fine-stranded annealed bare or tinned copper wire (PN-EN 60228 / IEC 60228 Class 5)PN-EN 60228 Class 5
2	Separator foil	Polyester or non-woven tape over the conductor preventing elastomer adhesionPN-91/E-90103
3	EPR core insulation (GIE1)	Cross-linked ethylene-propylene rubber compound Type GIE1 / EI4-EI7 (+90 °C rated)PN-91/E-90103
4	Inner elastomeric filling	Extruded rubber filler or inner sheath on heavy multicore sizes for impact resistancePN-91/E-90103
5	Mining PCP outer sheath (ON-3)	Cross-linked polychloroprene (neoprene) compound Type ON-3 / EM2, flame-retardant and oil-resistantPN-91/E-90103 · IEC 60332-1-2 · EN 60811-404

OnG 450/750 V (2×1.5 to 5×16 & 7–19C)

Light-to-medium mining and auxiliary control cables to PN-91/E-90103

OnG 0.6/1 kV (1×10–1×240 & 3×1.5–5×95)

Heavy-duty 0.6/1 kV mining power and trailing cables to PN-89/E-90143 / WT-TFK

Technical data

Ratings & operating limits

Typical values: Typical values for this cable type, based on PN-91/E-90103 / PN-89/E-90143. Values for your order are confirmed in the datasheet and quotation.

Electrical

Rated voltage U0/U: 450/750 V or 0.6/1 kV (600/1000 V AC)
AC test voltage: 2500 V AC (450/750 V) · 3000 V AC (0.6/1 kV), 50 Hz
Conductor stranding: PN-EN 60228 / IEC 60228 Class 5 flexible copper
Insulation resistance: ≥ 20 MΩ·km at +20 °C
Current rating basis: 90 °C EPR thermoset conductor rating

Thermal

Max. conductor temperature: +90 °C continuous operation
Short-circuit temperature: +250 °C max. (up to 5 s)
Temperature, flexing: −25 °C to +70 °C
Temperature, fixed: −40 °C to +70 °C

Mechanical

Min. bending radius, fixed: 4 × overall diameter
Min. bending radius, moving: 6 × overall diameter
Max. tensile load: 15 N/mm² of total copper cross-section
Mechanical impact class: Heavy mining & industrial trailing duty ('Oponowy Górniczy')

Resistance

Flame retardance ('n'): PN-EN 60332-1-2 / IEC 60332-1-2 self-extinguishing mining sheath
Oil & grease resistance ('n'): PN-EN 60811-404 mineral oil, diesel & hydraulic emulsion resistant
Mine water & humidity: Resistant to underground dampness, mud and coal dust
Weather & ozone: Ozone-resistant GIE1 EPR and ON-3 polychloroprene sheath

Reference standards

Construction standards: PN-91/E-90103 & PN-89/E-90143
European equivalent: Comparable to DIN VDE 0250-812 NSSHÖU / EN 50525-2-21 H07RN-F
Conductor standard: PN-EN 60228 / IEC 60228 Class 5
RoHS & REACH: 2011/65/EU (RoHS 2) & EC 1907/2006 compliant

Identification

Sheath colour: Black (or yellow/orange for mining visibility)
Core identification: Up to 5 cores: HD 308 S2 colour code · ≥ 6 cores: numbered + GN/YE
Sheath marking: TEBAOFLEX OnG [Size] 450/750V or 0.6/1kV PN-91/E-90103 CE
Customs tariff (HS): 8544.49 (insulated conductors ≤ 1000 V)

Sizes

24 standard OnG configurations

Typical PN-91/E-90103 / PN-89/E-90143 outer diameter limits, copper content and cable weight.

Dimensions & weights
Order designation	Cores × mm²	AWG ≈	Outer Ø min mm	Outer Ø max mm	Copper kg/km	Weight ≈ kg/km	Min. bend R mm
OnG Single-Core 0.6/1 kV Mining & Industrial Power Leads (25–240 mm²)
OnG 1×25 (0.6/1 kV)	1×25	4	11.6	12.6	240	335	50
OnG 1×50 (0.6/1 kV)	1×50	1	14.9	16.2	480	610	65
OnG 1×95 (0.6/1 kV)	1×95	3/0	19.3	21.0	912	1,110	84
OnG 1×150 (0.6/1 kV)	1×150	300 kcmil	23.6	25.6	1,440	1,710	102
OnG 1×240 (0.6/1 kV)	1×240	500 kcmil	29.0	31.5	2,304	2,660	126
OnG Multicore Power Cables (3G1.5–4G95)
OnG 3×1.5	3G1.5	16	9.8	10.6	43	155	42
OnG 4×1.5	4G1.5	16	10.7	11.6	58	190	46
OnG 5×1.5	5G1.5	16	11.8	12.8	72	235	51
OnG 3×2.5	3G2.5	14	11.2	12.2	72	220	49
OnG 4×2.5	4G2.5	14	12.3	13.4	96	270	54
OnG 5×2.5	5G2.5	14	13.6	14.8	120	330	59
OnG 4×4	4G4	12	14.4	15.6	154	390	62
OnG 4×6	4G6	10	16.1	17.5	230	520	70
OnG 4×10	4G10	8	20.1	21.8	384	860	87
OnG 4×16	4G16	6	23.2	25.2	614	1,210	101
OnG 4×25	4G25	4	27.8	30.2	960	1,780	121
OnG 4×35	4G35	2	31.3	34.0	1,344	2,350	136
OnG 4×50	4G50	1	36.3	39.5	1,920	3,220	158
OnG 4×70	4G70	2/0	41.0	44.6	2,688	4,310	178
OnG 4×95	4G95	3/0	46.2	50.2	3,648	5,650	201
OnG Multicore Mining Control & Signalling Cables (7G1.5–12G2.5)
OnG 7×1.5	7G1.5	16	14.0	15.2	101	330	61
OnG 12×1.5	12G1.5	16	17.8	19.4	173	520	78
OnG 7×2.5	7G2.5	14	16.4	17.8	168	470	71
OnG 12×2.5	12G2.5	14	20.8	22.6	288	760	90

Typical values for this cable type; dimensions and weights for your order are confirmed in the quotation.
Dimensions and weights are typical values per PN-91/E-90103 / PN-89/E-90143. Minimum fixed bending radius shown is 4 × OD.

Electrical & current ratings
Cross-section mm²	AWG ≈	Max. DC resistance 20 °C, Ω/km	1-core in air 30 °C, A	3–4 core in air 30 °C, A
1.5	16	13.3	23	18
2.5	14	7.98	30	25
4	12	4.95	41	34
6	10	3.3	53	44
10	8	1.91	74	61
16	6	1.21	99	82
25	4	0.78	131	108
35	2	0.554	162	135
50	1	0.386	202	168
70	2/0	0.272	250	207
95	3/0	0.206	301	250
150	300 kcmil	0.129	404	335
240	500 kcmil	0.08	540	453

Current ratings at 30 °C ambient in free air per DIN VDE 0298-4 / EN 50565-1. Apply derating factors for elevated ambient temperature or reeling layer grouping.

Reel check

Will it fit your machine?

A first screen using datasheet values. Engineering confirms drum geometry, acceleration and tension with your quotation.

Cable sizeDrum core diameter (mm)

Cable length on drum (m)

Drum core 300 mm ≥ 242 mmBending radius OK (4 × OD 30.2 mm)

Minimum bending radius: 121 mm
Min. drum core diameter: ≈ 242 mm
Cable weight on drum: 89.0 kg
Copper content: 48.0 kg

Indicative only: based on the datasheet outer diameter and 4 × OD bending radius. Current derating for wound layers per DIN VDE 0298-4 is assessed separately.

Quality & approvals

Testing & inspection

Routine tests on every production length, sample and type tests per batch — documented on an EN 10204 3.1 inspection certificate.

ConductorClass 5 stranding
Spark test100 % in-line
Lay-upCores, earth, fillers
SheathingInner, braid / screen, outer
Electrical testsAC voltage, resistance
DimensionsOD, wall thickness
Inspection documents & dispatchDrum & dispatch

Testing & inspection	Test value / reference	Frequency
Routine tests
AC voltage test	3.0 kV AC (50 Hz)	Every manufactured length
Conductor DC resistance	IEC 60228 Class 5 (bare copper)	Every manufactured length
Sample tests
Vertical flame propagation	IEC 60332-1-2 / EN 60332-1-2	Per production batch
Insulation & sheath elastomer physical properties	PN-91/E-90103 / PN-89/E-90143	Type approval

Inspection certificate

Issued with every drum, listing the routine test results for that length.

Product approvals

PN-91/E-90103 / PN-89/E-90143CE · RoHS 2 (2011/65/EU) · REACH

Company certificates

ISO 9001ISO 14001ISO 45001VDE marks approvalUL / cULCE · LVD / EMC

Marking & supply

Ordering & delivery

Sheath marking

TEBAOFLEX OnG [Size] 0.6/1 kV PN-91/E-90103 CE

Delivery form: Export wooden drums or coils, cut-to-length on request
Packaging: Heat-treated ISPM-15 timber drums with sealed cable ends
Conductor / sheath options: Custom core counts, pilot cores or sheath colours on request

Technical documents

Downloads

PDFOnG Cable – technical datasheet24 sizes · construction, technical data, approvals XLSXOnG spec data (Excel)All 24 sizes with dimensions and data, for your BOM or quotation

Revision: 2026-10-20
Updated: 2026-10-20

FAQ

Questions engineers ask first

Not covered here? Send your drawing — an engineer replies within 2 business hours.

What does the Polish cable designation 'OnG' mean?

In Polish standard PN-91/E-90103 nomenclature: 'O' stands for 'przewód oponowy' (heavy tire-grade rubber-sheathed flexible cable); 'n' stands for 'niepalny i olejoodporny' (flame-retardant and mineral-oil-resistant outer sheath); and 'G' stands for 'górniczy' (approved for mining service).

How does OnG compare with H07RN-F and NSSHÖU?

OnG bridges the gap between harmonised H07RN-F and German DIN VDE 0250-812 NSSHÖU: it uses +90 °C EPR core insulation (GIE1) rather than +60 °C EI4, and is produced in both 450/750 V (PN-91/E-90103) and heavy-duty 0.6/1 kV (PN-89/E-90143) executions with a mining-grade flame-retardant polychloroprene outer sheath (ON-3).

Where is OnG permitted in underground mines?

Under Polish mining regulations, OnG is used for mobile and semi-fixed electrical equipment in open-pit mines, coal preparation plants and underground mine excavations outside methane-hazard Degree 'b' and 'c' face zones (where screened cables such as OnGc or NSSHÖU/SSHCÖU are required).

Is OnG available with tinned copper conductors?

Yes. Both bare annealed Class 5 copper (standard per PN-91/E-90103 with polyester separator tape) and tinned Class 5 copper conductors are available on request.
