MIL-DTL-24643/3 LSDCOP/LSTCOP cordMIL-DTL-24643/3 (M24643/3)LSDCOP (2C) & LSTCOP (3C) · 600 VWatertight · LSZH · Shore-to-Ship

LSDCOP / LSTCOP MIL-DTL-24643 LSDCOP / LSTCOP Watertight PortableMIL-DTL-24643/3 600 V watertight low-smoke zero-halogen portable shipboard & shore cord

US Navy MIL-DTL-24643/3 (M24643/3) watertight, flexing, low-smoke zero-halogen (LSZH) portable shipboard power cord in two-conductor (LSDCOP) and three-conductor (LSTCOP) configurations (#18 AWG to #1/0 AWG) with rope-lay tinned copper, XLPO insulation.

Water-resistant
Flame-retardant
Oil-resistant
Approved
Order designation
M24643/3-15UN (LSTCOP-40)
Outer Ø ≈
26.2 mm
Copper weight
600 kg/km
Total weight ≈
1,140 kg/km
Ampacity
85 A
All sizes (8)
Request a quoteDatasheetWhatsApp
Engineering reply in 2 business hoursCut-to-length export drumsEN 10204 3.1 certificate per drum
Mil-Spec
M24643/3
LSDCOP (2-core) & LSTCOP (3-core)
Rated voltage
600 V AC / DC
portable shipboard & shore cord
Watertightness
Water-blocked
longitudinal & radial watertight
Compound
LSZH XLPO
cross-linked polyolefin insul/jkt
Temp. rating
−30 to +105 °C
continuous conductor temperature
Min. bend R
6 × OD
portable deck & pier handling

Typical values for this cable type, based on MIL-DTL-24643/3 (M24643/3) / IEEE 45 / MIL-STD-2042 — confirmed in the datasheet and quotation for your order.

Application fit

Is LSDCOP / LSTCOP right for your machine?

Specified across US Navy and allied surface combatants, amphibious ships and auxiliaries for portable deck equipment, damage-control submersible dewatering pumps, temporary lighting strings and pier-to-ship shore power jumpers.

Quayside shore-to-ship HVSC connection

Suitable

Used for portable pier-to-ship power cords, temporary shipboard maintenance power and dockside generator hookups.

Offshore platform & shipboard deck trays

Suitable

Cross-linked LSZH XLPO jacket resists JP-5 aviation fuel, F-76 naval distillate, hydraulic oil and salt-spray weathering.

Immersion & wet locations

Suitable

Internal water-blocking elastomeric fillers prevent longitudinal water migration between watertight shipboard compartments.

Typical machinesUS Navy & Allied Surface CombatantsPier-to-Ship Shore Power & Dockside MaintenanceShipboard Damage-Control Dewatering PumpsCoast Guard, Auxiliary & Research Vessels

Construction

Layer by layer

Shown: M24643/3-15UN (LSTCOP-40, 3×4 AWG) 600 V with flexible rope-lay tinned copper conductors, cross-linked polyolefin (XLPO) insulation, elastomeric water-blocking interstices, reinforcing binder braid and black cross-linked LSZH polyolefin outer jacket.

1234
Schematic, not to scale — generated from the layer data
#LayerMaterial & reference
1Flexible rope-lay stranded tinned copperASTM B33 / MIL-DTL-24643 flexible bunched or rope-lay tinned copper (#18 AWG to #1/0 AWG)Resists marine sulphide/salt corrosion and survives repeated deck coiling
2Low-smoke zero-halogen cross-linked polyolefin (XLPO)105 °C thermoset LSZH XLPO compound (Black, White, Red core ID)High dielectric strength with zero halogen acid-gas emission during shipboard fire
3Longitudinal water-blocking elastomeric compoundVoid-free non-hygroscopic water-blocking filler matrix + reinforcing fabric binderPrevents compartment-to-compartment flooding through the cable core at rated hydrostatic head
4Cross-linked LSZH polyolefin heavy-duty portable jacketAbrasion-, oil- and sunlight-resistant thermoset LSZH XLPO outer jacket (Black)Passes IEEE 1202 / MIL-DTL-24643 vertical flame, smoke index and toxicity tests

LSDCOP (M24643/3-01UN to -08UN · 2-Conductor)

Low-Smoke Double Conductor Oil-resistant Portable watertight cord (LSDCOP-2 to LSDCOP-50)

LSTCOP (M24643/3-09UN to -18UN · 3-Conductor)

Low-Smoke Triple Conductor Oil-resistant Portable watertight cord (LSTCOP-2 to LSTCOP-133)

Technical data

Ratings & operating limits

Typical values: Typical values for this cable type, based on MIL-DTL-24643/3 (M24643/3) / IEEE 45 / MIL-STD-2042. Values for your order are confirmed in the datasheet and quotation.

Electrical

Rated operating voltage
600 V AC / DC rms
Factory AC dielectric withstand test
2.0 to 3.0 kV AC rms for 5 minutes + IR ≥ 1,000 MΩ·1000 ft

Thermal

Conductor temperature rating
−30 °C to +105 °C continuous · +250 °C short-circuit
Thermal cycling & overload stability
Verified thermal ageing and short-circuit withstand per standard

Mechanical

Longitudinal watertightness (WT)
Passes MIL-DTL-24643 hydrostatic longitudinal water-penetration test
Minimum bending radius
6 × OD (dynamic portable flexing) · 5 × OD (stowed)

Resistance

Low-smoke & zero-halogen toxicity
Halogen content < 0.2 % · Acid gas < 5 mg/g · NES 713 toxicity & smoke
Naval fluid & fuel resistance
Resists JP-5 jet fuel, F-76 marine diesel, MIL-PRF-17672 lube oil &

Reference standards

Governing military specification
MIL-DTL-24643/3 (Slash Sheet 3) · Supersedes legacy MIL-C-915 DCOP / TCOP
Factory QA & material compliance
EN 10204 3.1 routine test certificate · RoHS 2 & REACH compliant

Identification

Military part-number nomenclature
LSDCOP-<MCM> / LSTCOP-<MCM> (e.g. LSTCOP-40 ≈ 40 kcmil / 4 AWG)
Customs tariff (HS)
8544.49

Sizes

8 standard MIL-DTL-24643/3 LSDCOP & LSTCOP portable shipboard cords

2-conductor (LSDCOP) and 3-conductor (LSTCOP) 600 V watertight LSZH portable shipboard cables.

Military PIN, AWG size, outer diameter & ampacity
Military PIN / TypeConductorsVoltageOuter Ø ≈
mm		Copper
kg/km		Weight ≈
kg/km		Ampacity
A		Min. bend R
mm		Enquiry
LSDCOP — 2-Conductor 600 V Watertight Portable Shipboard Cords (M24643/3)
M24643/3-02UN (LSDCOP-4)2×14 AWG (2.08 mm²)600 V10.7401452064
M24643/3-04UN (LSDCOP-9)2×10 AWG (5.26 mm²)600 V14.51002683587
M24643/3-06UN (LSDCOP-23)2×6 AWG (13.3 mm²)600 V20.625056565124
LSTCOP — 3-Conductor 600 V Watertight Portable & Shore Power Cords (M24643/3)
M24643/3-09UN (LSTCOP-3)3×16 AWG (1.31 mm²)600 V10.4381421562
M24643/3-11UN (LSTCOP-6)3×12 AWG (3.31 mm²)600 V13.7952552582
M24643/3-13UN (LSTCOP-14)3×8 AWG (8.37 mm²)600 V19.323853550116
M24643/3-15UN (LSTCOP-40)3×4 AWG (21.2 mm²)600 V26.26001,14085157
M24643/3-18UN (LSTCOP-100)3×1/0 AWG (53.5 mm²)600 V35.81,5102,520150215
  • Typical values for this cable type; dimensions and weights for your order are confirmed in the quotation.
  • Full M24643/3 range covers LSDCOP-2 through LSDCOP-50 and LSTCOP-2 through LSTCOP-133.

Quality & approvals

Testing & inspection

Routine tests on every production length, sample and type tests per batch — documented on an EN 10204 3.1 inspection certificate.

  1. ConductorClass 5 stranding
  2. Spark test100 % in-line
  3. Lay-upCores, earth, fillers
  4. SheathingInner, braid / screen, outer
  5. Electrical testsAC voltage, resistance
  6. DimensionsOD, wall thickness
  7. Inspection documents & dispatchDrum & dispatch
Testing & inspectionTest value / referenceFrequency
Routine tests
MIL-DTL-24643 AC dielectric withstand, IR & longitudinal watertightness testZero breakdown; water migration within strict M24643/3 hydrostatic limitEvery production reel
Sample tests
IEEE 1202 vertical tray flame, smoke index, acid gas & flex-endurance testMeets NAVSEA low-smoke zero-halogen and portable flexing criteriaLot qualification

Inspection certificate

Issued with every drum, listing the routine test results for that length.

Product approvals

MIL-DTL-24643/3 (M24643/3) CompliantLow-Smoke Zero-Halogen (LSZH) & WatertightIEEE 45 & MIL-STD-2042 Shipboard Practice

Company certificates

ISO 9001ISO 14001ISO 45001VDE marks approvalUL / cULCE · LVD / EMC

Marking & supply

Ordering & delivery

Sheath marking

TEBAOFLEX M24643/3-<PIN> LSDCOP/LSTCOP-<size> 600V WT LSZH YEAR
Delivery form
Non-returnable fumigated wooden or steel drums
Standard lengths
250 m · 500 m · 1000 m standard drums
MOQ
250 m (stock sizes) · 500 m (custom)
Lead time
3–5 weeks ex-works
Incoterms
EXW, FCA, FOB, CIF, DAP

Technical documents

Downloads

PDFLSDCOP / LSTCOP MIL-DTL-24643 LSDCOP / LSTCOP Watertight Portable – technical datasheet8 sizes · construction, technical data, approvalsXLSXLSDCOP / LSTCOP spec data (Excel)All 8 sizes with dimensions and data, for your BOM or quotation
Revision
2026-10-20
Updated
2026-10-20

FAQ

Questions engineers ask first

Not covered here? Send your drawing — an engineer replies within 2 business hours.

What do the letters LSDCOP and LSTCOP stand for in MIL-DTL-24643/3?
'LS' stands for Low-Smoke (zero-halogen cross-linked polyolefin, replacing the legacy chlorinated MIL-C-915 DCOP/TCOP cords); 'D' stands for Double conductor (2 cores) and 'T' stands for Triple conductor (3 cores); 'COP' stands for Cord, Oil-resistant, Portable. The trailing number (e.g. LSTCOP-40) indicates the approximate conductor cross-section in thousands of circular mils (40 ≈ 40,000 cmil = 4 AWG).
Why must portable shipboard cords be longitudinally watertight ('UN' / WT)?
When a portable or semi-permanent cable passes through a watertight bulkhead stuffing tube between ship compartments, an unblocked cable core could act as a hose and flood an adjacent compartment if one space is breached below the waterline. LSDCOP and LSTCOP fill all internal interstices so water cannot migrate along the cable core.
How does LSDCOP/LSTCOP differ from LSDSGU/LSTSGU and LSDPS/LSTPS?
LSDCOP/LSTCOP (M24643/3) are flexible portable cords for deck equipment and shore jumpers; LSDSGU/LSTSGU (M24643/15 & /16) are fixed shipboard power feeder cables; and LSDPS/LSTPS (M24643/32 & /33) are 1,000–1,500 psi high-pressure submarine hull-penetration cables.
What factory routine tests and certificates are supplied with LSDCOP / LSTCOP?
Every production drum of LSDCOP / LSTCOP undergoes 100 % conductor DC resistance measurement at 20 °C, high-voltage AC/DC dielectric withstand testing, and dimensional verification per MIL-DTL-24643/3 (M24643/3) / IEEE 45 / MIL-STD-2042, supplied with an EN 10204 3.1 inspection certificate.
